| 4WG180 4WG200 TRANSMISSION SPARE PARTS |
| GEARBOX HOUSING ASSEMBLY 4644 101 | 12 0730108158 SHIM S=1.6 0730 108 158 |
| 1 4644301391 GEARBOX HOUSING 4644 301 391 | 13 0730108159 SHIM S=1.8 0730 108 159 |
| 2 0336302027 PLUG (M30*1.5)0336 302 027 | 14 0730108160 SHIM S=2.0 0730 108 160 |
| 3 0634304275 O-RING (27*2)0634 304 275 | 15 0730108161 SHIM S=2.2 0730 108 161 |
| 4 0899317344 TYPE PLATE 0899 317 344 | 16 0730108162 SHIM S=2.4 0730 108 162 |
| 5 0631311009 RIVET 0631 311 009 | 17 0730108163 SHIM S=2.6 0730 108 163 |
| 6 0636305046 PLUG (AM14*1.5)0636 305 046 | 18 0730108164 SHIM S=2.8 0730 108 164 |
| 7 0634306522 O-RING 0634 306 522 | 19 0730150759 THRUST WASHER 0730 150 759 |
| 8 4644301298 COVER PLATE 4644 301 298 | 20 4644303529 THRUST WASHER 4644 303 529 |
| 9 4644301192 COVER PLATE 4644 301 192 | 21 4644308625 GEAR (Z=63)4644 308 625 |
| 10 0636015278 SCREW (M8*16)0636 015 278 | 22 4644308265 THRUST WASHER 4644 308 265 |
| 11 0630001012 WASHER 0630 001 012 | 23 0730150773 THRUST WASHER 0730 150 773 |
| 12 4466351081 SEALED CAP 4466 351 081 | 24 0750119100 ROLL.BEARING ASSEMBLY 0750 119 100 |
| 13 0634306525 O-RING 0634 306 525 | 25 4644308266 WASHER 4644 308 266 |
| 14 0636305026 PLUG (CM38*1.5)0636 305 026 | 26 4644308071 WASHER 4644 308 071 |
| 15 0636305019 PLUG (AM26*1.5)0636 305 019 | 27 4644351070 PISTON 4644 351 070 |
| 16 0634303233 O-RING 0634 303 233 | 28 0750112139 PACKING RING 0750 112 139 |
| 17 0750131027 PERMEABILITY PARTS 0750 131 027 | 29 4644351094 THRUST WASHER 4644 351 094 |
| 18 4644301279 CLAPBOARD 4644 301 279 | 30 4642308555 THRUST WASHER 4642 308 555 |
| 19 0636804003 BOLT 0636 804 003 | 31 0750112140 PACKING RING 0750 112 140 |
| 20 4644301088 SEALED CAP 4644 301 088 | 32 0732041183 PRESSURE SPRING 0732 041 183 |
| LAYSHAFT 4644 108 | 33 4642308083 GUIDE RING 4642 308 083 |
| 1 4644308611 SHAFT 4644 308 611 | 34 550630531346 V-CUP 550630531346 |
| 2 0634313529 O-RING 0634 313 529 | 35 4642308084 GUIDE RING 4642 308 084 |
| 3 4644308610 THRUST WASHER 4644 308 610 | 36 0635303203 NEEDLE BEARING 0635 303 203 |
| 4 4644308614 IDLEER GEAR SHAFT Z=36(HVZ)4644 308 614 | 37 0730513610 RETAINING RING 0730 513 610 |
| 5 0636104146 CAP SCREW 0636 104 146 | 38 0635303205 NEEDLE BEARING 0635 303 205 |
| 6 0750119101 ROLL.BEARING ASSEMBLY 0750 119 101 | 39 0730513611 RETAINING RING 0730 513 611 |
| 7 0630362024 PACKING WASHER (25)0630 362 024 | 40 0730513181 RETAINING RING 0730 513 181 |
| COUPLNG KV+K1 4644 151 | 41 0730513434 SNAP RING 0730 513 434 |
| 1 4644351076 SHAFT 4644 351 076 | 42 0730513436 SNAP RING 0730 513 436 |
| 2 0634313536 O-RING (49*3)0634 313 536 | 43 0730513459 SNAP RING 0730 513 459 |
| 3 0734401106 PISTON RING 0734 401 106 | 44 0730513457 SNAP RING 0730 513 457 |
| 4 0636610014 DOUBLE-SCREW BOLT 0636 610 014 | 45 0730150779 THRUST WASHER 0730 150 779 |
| 5 0637006018 NUT 0637 006 018 | 46 4644252097 SPUR GEAR 4644 252 097 |
| 6 0730003501 WASHER 0730 003 501 | 47 0750115211 BALL BEARING 0750 115 211 |
| 7 0730003502 SHIM S=0.6 0730 003 502 | 48 0501308830 CERATOCRICOID MUSCLE 0501 308 830 |
| 8 0730003503 SHIM S=0.8 0730 003 503 | 49 4644252098 DISC CARRIER 4644 252 098 |
| 9 0730003504 SHIM S=1.0 0730 003 504 | 50 0501309330 OUTER CLUTCH DISC 0501 309 330 |
| 10 0730003505 SHIM S=1.2 0730 003 505 | 51 4644308329 INTERNAL FRICTION BLOCK 4644 308 329 |
| 11 0730108157 SHIM S=1.4 0730 108 157 | 52 4644308330 INTERNAL FRICTION BLOCK 4644 308 330 |
